EP414T3 TRACK DRIVES (GFT80T3)
EP414W3 WINCH DRIVES (GFT80W3)

EP414T3 TRACK DRIVES (GFT80T3),EP414W3 WINCH DRIVES (GFT80W3)

Technical specification


Max.Output Torque
(N.m)

Ratio
(i)

Recommend Hydraulic Motor

Max. input speed
(rpm)

Brake torque
(N.m)

Brake work pressure
(bar)

EP414T3

EP414W3

80000

67000

78.4
84.3
100.8
128.9
159
186.7

A2FE160กค180
A2FE107กค125
A6VE107กค160

3500

1200

20-50

    • Input rotation opposite output rotation.
    • Other ratio and other input type can be specially designed.



    Back To Planetary GearBox
