EP406AT3 TRACK DRIVES (GFT17T3 1000)
EP406AW3 WINCH DRIVES (GFT17W3 1000)

EP406AT3 TRACK DRIVES (GFT17T3 1000), EP406AW3 WINCH DRIVES (GFT17W3 1000)

Technical specification


Max.Output Torque
(N.m)

Ratio
(i)

Recommend Hydraulic Motor

Max. input speed
(rpm)

Brake torque
(N.m)

Brake work pressure
(bar)

EP406AT3

EP406AW3

18000

12500

70.3
80.0
94.5
110.9
136.1
173
219.4

A2FE28กค32
A2FE45กค56กค63
A6VE28กค55

4000

430

20-50

  1. Input rotation opposite output rotation.
  2. Other ratio and other input type can be specially designed.



Back To Planetary GearBox
